Description
All Deliveries made within 24 Hours (Business Hours) post receipt of order. Except Fridays (Weekly Off)
Get GST invoice and save upto 28 % on business purchases. T&C Apply.
1 year on product and 5 year only compressor warranty
Specification HYBRID+ HEAVY DUTY AC (R32)
Model – Indoor Unit: SRK25 CWX-S6
Model – Outdoor Unit:: SRC25 CWX-S6
Tonnage: 1.95
BEE STAR RATING – 3 star
Refrigerant Control & Expansion: Dual Capillary Expansion
Fixed Speed Compressor Type: Super Tropical – Return Cooled Rotary
Power Source: 1 Phase, 230 V, 50 Hz
Rated Cooling Capacity at 100% Load – BTU/hr: 23458
Rated Cooling Capacity at 50% Load – BTU/hr: Not Applicable for Fixed Speed AC
Rated Cooling Capacity at 100% Load – Watts: 6875
Rated Cooling Capacity at 50% Load – Watts: Not Applicable for Fixed Speed AC
Rated Power Consumption at 100% Load – watts: 1635
Rated Power Consumption at 50% Load – watts: Not Applicable for Fixed Speed AC
Rated EER / COP at 100% Load – W/w:4.20
Rated EER / COP at 50% Load – W/w: Not Applicable for Fixed Speed AC
BEE Rated Indian Seasonal Energy Efficiency Ratio by ISEER: 3.77
Input Power ** ( Minimum ~ Maximum) – Watts: 1385 ~ 1635
Current ( minimum ~ maximum ) ** – A: 6.2 ~ 7.3
Model – Indoor Unit: SRK25 CWX-S6
Model – Outdoor Unit:: SRC25 CWX-S6
Tonnage: 1.95
BEE STAR RATING – 3 star
Refrigerant Control & Expansion: Dual Capillary Expansion
Fixed Speed Compressor Type: Super Tropical – Return Cooled Rotary
Power Source: 1 Phase, 230 V, 50 Hz
Rated Cooling Capacity at 100% Load – BTU/hr: 23458
Rated Cooling Capacity at 50% Load – BTU/hr: Not Applicable for Fixed Speed AC
Rated Cooling Capacity at 100% Load – Watts: 6875
Rated Cooling Capacity at 50% Load – Watts: Not Applicable for Fixed Speed AC
Rated Power Consumption at 100% Load – watts: 1635
Rated Power Consumption at 50% Load – watts: Not Applicable for Fixed Speed AC
Rated EER / COP at 100% Load – W/w:4.20
Rated EER / COP at 50% Load – W/w: Not Applicable for Fixed Speed AC
BEE Rated Indian Seasonal Energy Efficiency Ratio by ISEER: 3.77
Input Power ** ( Minimum ~ Maximum) – Watts: 1385 ~ 1635
Current ( minimum ~ maximum ) ** – A: 6.2 ~ 7.3
Dimension (H x W x D) – Indoor Unit – mm: 339 x 1197 x 262
Dimension (H x W x D) – Outdoor Unit – mm: 750 x 880 (+88) x 340
Weight – Indoor Unit – Kgs: 17
Weight – Outdoor Unit – Kgs: 63.5
Air Flow ( CMH ) – Indoor Unit – m3/hr: 1400
Long Reach AirFlow Upto – Indoor Unit – Meter: 18.29
Sound Level (H/M/L) – Indoor Unit – dB: 47 / 43 / 40
Louver Swing – Indoor Unit: 3D + 3D AUTO
Special Filter – Indoor Unit: Natural Enzyme + Photocatalytic Deodorizing Filter + Anti Bacterial
Blower Fan – Indoor Unit: Anti – Micro Bial
DC Fan Motor Speed – Indoor Unit: Auto / Powerful / High / Med / Low/ Dry
Refrigerant: R410A
Refrigerant Piping – Liquid Line – mm: 6.35 ( 1/4″ )
Refrigerant Piping – Gas Line – mm: 15.88 ( 3/8″ )
Main Power Supply to – Indoor Unit: 2.5 mm2 x 3 cores (including earthing cable )
Connecting wiring between B/w IDU &: 2.5 mm2 x 4 cores (including earthing cable )
Area Coverage *** – Sq. Meter: 27.88 ~ 37.17
Dimension (H x W x D) – Outdoor Unit – mm: 750 x 880 (+88) x 340
Weight – Indoor Unit – Kgs: 17
Weight – Outdoor Unit – Kgs: 63.5
Air Flow ( CMH ) – Indoor Unit – m3/hr: 1400
Long Reach AirFlow Upto – Indoor Unit – Meter: 18.29
Sound Level (H/M/L) – Indoor Unit – dB: 47 / 43 / 40
Louver Swing – Indoor Unit: 3D + 3D AUTO
Special Filter – Indoor Unit: Natural Enzyme + Photocatalytic Deodorizing Filter + Anti Bacterial
Blower Fan – Indoor Unit: Anti – Micro Bial
DC Fan Motor Speed – Indoor Unit: Auto / Powerful / High / Med / Low/ Dry
Refrigerant: R410A
Refrigerant Piping – Liquid Line – mm: 6.35 ( 1/4″ )
Refrigerant Piping – Gas Line – mm: 15.88 ( 3/8″ )
Main Power Supply to – Indoor Unit: 2.5 mm2 x 3 cores (including earthing cable )
Connecting wiring between B/w IDU &: 2.5 mm2 x 4 cores (including earthing cable )
Area Coverage *** – Sq. Meter: 27.88 ~ 37.17
Made In Thailand
Mahajan Electronics
89-90 Raja Garden
New Delhi-110015
