- Warranty: 1 year warranty on product and 5 years warranty on compressor
- Condenser Type: Copper for best in class, energy efficient cooling with easy maintenance
- Special Features: Anti dust filter, Sleep mode, Turbo mode, Auto restart.
- Type : 2 STAR Non Inverter Split AC
- 2.2 Ton
- 2 Star BEE Rating : For energy savings upto 15% (compared to Non-Inverter 1 Star)
- Auto Restart: No need to manually reset the settings post power-cut
- Copper : Energy efficient, best in class cooling with easy maintenance.
- Sleep Mode: Auto-adjusts the temperature to ensure comfort during your sleep
Specification HYBRID+ HEAVY DUTY AC (R410A)
Model – Indoor Unit: SRK25CSS-S6/A
Model – Outdoor Unit:: SRC25CSS-S6/A
Tonnage: 2.2
BEE STAR RATING –: 2 Star
Refrigerant Control & Expansion: Dual Capillary Expansion
Fixed Speed Compressor Type: Super Tropical – Return Cooled Rotary
Power Source: 1 Phase, 230 V, 50 Hz
Maximum Cooling Capacity* – BTU/hr: 26272
Rated Cooling Capacity at 100% Load – BTU/hr: 26017
Rated Cooling Capacity at 50% Load – BTU/hr: Not Applicable for Fixed Speed AC
Maximum Cooling Capacity* – Watts: 7700
Rated Cooling Capacity at 100% Load – Watts: 7625
Rated Cooling Capacity at 50% Load – Watts: Not Applicable for Fixed Speed AC
Rated Power Consumption at 100% Load – watts: 2050
Rated Power Consumption at 50% Load – watts: Not Applicable for Fixed Speed AC
Rated EER / COP at 100% Load – W/w:3.72
Rated EER / COP at 50% Load – W/w: Not Applicable for Fixed Speed AC
BEE Rated Indian Seasonal Energy Efficiency Ratio by ISEER: 3.72
Input Power ** ( Minimum ~ Maximum) – Watts: 1800 ~ 2050
Current ( minimum ~ maximum ) ** – A: 8.0 ~ 9.2
Model – Indoor Unit: SRK25CSS-S6/A
Model – Outdoor Unit:: SRC25CSS-S6/A
Tonnage: 2.2
BEE STAR RATING –: 2 Star
Refrigerant Control & Expansion: Dual Capillary Expansion
Fixed Speed Compressor Type: Super Tropical – Return Cooled Rotary
Power Source: 1 Phase, 230 V, 50 Hz
Maximum Cooling Capacity* – BTU/hr: 26272
Rated Cooling Capacity at 100% Load – BTU/hr: 26017
Rated Cooling Capacity at 50% Load – BTU/hr: Not Applicable for Fixed Speed AC
Maximum Cooling Capacity* – Watts: 7700
Rated Cooling Capacity at 100% Load – Watts: 7625
Rated Cooling Capacity at 50% Load – Watts: Not Applicable for Fixed Speed AC
Rated Power Consumption at 100% Load – watts: 2050
Rated Power Consumption at 50% Load – watts: Not Applicable for Fixed Speed AC
Rated EER / COP at 100% Load – W/w:3.72
Rated EER / COP at 50% Load – W/w: Not Applicable for Fixed Speed AC
BEE Rated Indian Seasonal Energy Efficiency Ratio by ISEER: 3.72
Input Power ** ( Minimum ~ Maximum) – Watts: 1800 ~ 2050
Current ( minimum ~ maximum ) ** – A: 8.0 ~ 9.2
Dimension (H x W x D) – Indoor Unit – mm: 339 x 1197 x 262
Dimension (H x W x D) – Outdoor Unit – mm: 750 x 880 (+88) x 340
Weight – Indoor Unit – Kgs: 17
Weight – Outdoor Unit – Kgs: 60
Air Flow ( CMH ) – Indoor Unit – m3/hr: 1450
Long Reach AirFlow Upto – Indoor Unit – Meter: 18.28
Sound Level (H/M/L) – Indoor Unit – dB: 46 / 42 / 39
Louver Swing – Indoor Unit: 3D + 3D AUTO
Special Filter – Indoor Unit: Enzyme + Photocatalytic Deodorizing Filter + Anti Bacterial
Blower Fan – Indoor Unit: Anti – Micro Bial
DC Fan Motor Speed – Indoor Unit: Auto / Powerful / High / Med / Low/ Dry
Refrigerant Injection in Coil – Indoor Unit: 5 Point – Multi Port
Refrigerant Piping – Liquid Line – mm: 6.35 ( 1/4″ )
Refrigerant Piping – Gas Line – mm: 15.88 ( 5/8″ )
Main Power Supply to – Indoor Unit: 2.5 mm2 x 3 cores (including earthing cable )
Connecting wiring between B/w IDU &: 2.5 mm2 x 4 cores (including earthing cable )
Area Coverage *** – Sq. Meter: 27.87 ~ 41.80
Dimension (H x W x D) – Outdoor Unit – mm: 750 x 880 (+88) x 340
Weight – Indoor Unit – Kgs: 17
Weight – Outdoor Unit – Kgs: 60
Air Flow ( CMH ) – Indoor Unit – m3/hr: 1450
Long Reach AirFlow Upto – Indoor Unit – Meter: 18.28
Sound Level (H/M/L) – Indoor Unit – dB: 46 / 42 / 39
Louver Swing – Indoor Unit: 3D + 3D AUTO
Special Filter – Indoor Unit: Enzyme + Photocatalytic Deodorizing Filter + Anti Bacterial
Blower Fan – Indoor Unit: Anti – Micro Bial
DC Fan Motor Speed – Indoor Unit: Auto / Powerful / High / Med / Low/ Dry
Refrigerant Injection in Coil – Indoor Unit: 5 Point – Multi Port
Refrigerant Piping – Liquid Line – mm: 6.35 ( 1/4″ )
Refrigerant Piping – Gas Line – mm: 15.88 ( 5/8″ )
Main Power Supply to – Indoor Unit: 2.5 mm2 x 3 cores (including earthing cable )
Connecting wiring between B/w IDU &: 2.5 mm2 x 4 cores (including earthing cable )
Area Coverage *** – Sq. Meter: 27.87 ~ 41.80
| Country Of Origin - THAILAND |
| Capacity in Tons |
|
| Star Rating |
|
| BEE Rating Year |
|
| Color |
|
| Cooling and Heating |
|
| Cooling Capacity |
|
| Compressor |
|
| Dehumidification |
|
| Remote Control |
|
| Refrigerant |
|
| Technology Used |
|
| Condenser Coil |
|
Dimensions
| Indoor W x H x D |
|
| Indoor Unit Weight |
|
| Outdoor W x H x D |
|
| Outdoor Unit Weight |
|
| Remote Control Weight |
|
Performance Features
| Indoor Noise Level |
|
| Panel Display |
|
| Indoor Temperature Indicator |
|
| Cooling Coverage Area |
|
| Turbo Mode |
|
| ISEER |
|
Body And Design Features
| Evaporator Fin Type |
|
| Condenser Fin Type |
|
| Stepped Louvers |
|
Air Flow & Filter Features
Auto Air Swing
- Yes
- 4 Way
- No
- Yes
- No
- No
