Standard Installation offer @ Rs. 599 + GST (18%) for all Fixed speed and Inverter Split ACs for retail customers bought through offline channel partners.
1 year on product , 5 year PCB and 5 Year only compressor warranty.T&C
Warranty Registration:-SMS (WTA 9289525321) applicable on Domestic.
Get GST invoice and save upto 28 % on business purchases. T&C Apply.
Anti Microbial Air Filteration
Instant Cooling
Sleep Mode
Self Diagnosis
Glow Light Buttons
Product Specifications
|
|
|
|
| Rated Heating Capacity [W] |
5000 |
|
| Rated Cooling Capacity [W] |
4900 |
|
| Compressor Type |
High EER Rotary |
|
|
|
| Power Supply [V/Hz/Ph] |
230 / 50 / 1 Phase |
|
| Rated Power Input- Cooling [Watt] |
1750 |
|
| Rated Power Input- Heating [Watt] |
1400 |
|
| Rated Current- Cooling [Amps] |
7.7 |
|
| Rated Current- Heating [Amps] |
6.2 |
|
| Condenser Coil |
Copper (Coated Fin) |
|
| Connecting Pipe [Type] |
Cu-Cu(12.7mm & 6.35mm) |
|
Performance
| Star Rating |
AC with Intelligent Heating |
|
| Air Flow Volume - Indoor [CMH] |
900 |
|
| Noise Level - Indoor [..dB(A)] |
≤46 |
|
|
|
| Operating Ambient Temp Range[Deg C] |
0⁰ C ~ 46⁰ C |
|
Operation
Other Features
|
|
| Antimicrobial Protection |
No |
|
| HD filter |
Dual Filter Protection |
|
|
|
|
|
|
|
|
|
| Copper Tubes- Inner Grooved |
No |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Dimensions
| Indoor Unit Dimension (WxHxD) [cm] |
99x31.5x24.2 |
|
| Outdoor Unit Dimension (WxHxD) [cm] |
83.5x55.5x29.5 |
|
Unit Weight
| Indoor Unit Net / Gross Weight [Kg] |
12.8/16 |
|
| Outdoor Unit Net / Gross Weight [Kg] |
33.6/39.4 |
|
Made in india
