Description
All Deliveries made within 24 Hours (Business Hours) post receipt of order.
About this item
- Compressor type: Reciprocating
- Ideal Room Size: 250-400 sq./ft.
- Filters: Active Carbon and Dust filter
- Power Input (Supply): (415V/50Hz/3Ph)
-
Available in 4 Ton
100% Copper Condenser
1 Year Warranty on Compressor (4 Ton model)FEATURES:
- High Energy Efficiency Rotary Compressor
- Turbo Cool
- Wide Angle, Powerful Air Flow (Auto 2 Way Swing)
- iFeel
- 100% Copper
- Anti-Corrosive Gold Fins in Indoor & Blue Fins in Outdoor for Protection
- Self Diagnosis
- Comfort Sleep
| Nominal Cooling Capacity (TR) | 4.0 TR |
| Air Conditioner Type | Verticool |
| Star Rating - As Per BEE | 1-Star |
| (Rated) Voltage/Frequency/Phase | 415 V/50 Hz/3 Ph |
| Cooling Capacity (Min~Max) (Watt) | 12896 |
| Cooling Capacity (Min~Max) (BTU/Hr) | 44001 |
| Cooling Rated Power Input (Min~Max) (Watt) | 4750 |
| ISEER | 2.71 |
| Electricity Consumed in 1600 Hours (Units/Year) | 3677.01 |
| Nominal Current (Cooling in Amps)/Running Current | 8.5 |
| Air Flow Volume (Wet CFM) (High/Low) | 877/ 704 |
| Noise Level Indoor (High/Low) In dB(A) | 50.5/44.4 |
| Moisture Removal (Litres/Hour) | 5.2 |
| Compressor Type | Dual Rotary |
| Compressor Warranty | 1Year |
| Eco-Friendly Refrigerant | R-32 |
| Ambient Temp Range (Cooling)°C | Up to 52ºc |
| Remote | LCD Remote |
| IDU Net Dimension (W X H X D) mm | 550 x 1800 x 350 |
| Input Power Supply | OUTDOOR UNIT |
| Net Weight IDU | 47.2kg |
| ODU Net Dimension (W X H X D) mm | 1075 x 950 x 470 |
| Net Weight ODU | 86.6 Kg |
| Gross Weight ODU | 96 KG |
| Noise Level Outdoor In dB(A) | 73 |
| Power Supply to ODU Source(Core/Gauge) sqmm | 5C * 2.5 |
| Power Supply to IDU Source(Core/Gauge) sqmm | 4C * 1.5 |
| Cable from ODU to IDU (Communication Cable) sqmm | Included in ODU to IDU wire |
| Suction Tube Size Outer Diameter Inch (mm) | 3/4" (19.05mm) |
| Liquid Tube Size Outer Diameter Inch (mm) | 3/8'' (9.52mm) |
| Max Piping Capability Total (metre) | 20 |
| Max Piping Capability Vertical (metre) | 10 |
| Refrigerant Additional Charge Beyond 5M (g/m) | 15 |
Made in india
