Description
🎁 Exclusive at Mahajan Electronics — not available elsewhere:
1 Ton. 55°C Hyper Tropical. R32. 250V ✅.
Coanda 10m · 700V Protection · 701 kWh/yr · 2-Star.
Hyper Tropical Rotary Compressor · Silicon Coated PCB · 5-speed fan · 45dB indoor · 48dB outdoor · 100% copper · Auto Restart · IDU 10kg · ODU 21kg
3°C higher than the standard 52°C heavy-duty rating — engineered for India's most extreme conditions. Delhi NCR roof terraces, west-facing rooms, and commercial spaces in May–June regularly see surface temperatures exceeding 50°C. The Hyper Tropical Rotary Compressor is specifically designed to maintain stable full-load cooling output at ambient temperatures up to 55°C — where most inverter ACs throttle back or trigger compressor protection cutoff.
Coanda Airflow Technology — 10-metre cooling reach
Standard AC airflow follows a straight trajectory from the indoor unit — coverage drops sharply beyond 6–7 metres. Coanda airflow leverages the Coanda effect (a fluid's tendency to follow a curved surface) to guide cool air along the ceiling in a curved path, extending the effective reach to 10 metres. For a compact room (up to 100 sq ft), this means uniform cooling without cold spots directly below the unit or warm spots at the far wall — every position in the room receives equivalent air distribution.
Wide Voltage Protection up to 700V — protects the compressor and PCB from voltage spikes that occur during power restoration after cuts, transformer switching, and line faults. Delhi NCR experiences these regularly. Most ACs are rated for standard voltage tolerance (±10%); the 700V protection is significantly above this, providing meaningful protection in areas with unstable supply.
The printed circuit board is coated with silicon — sealing it against humidity, dust, and insect ingress that causes corrosion on standard PCBs. In Delhi NCR's humid monsoon months and dusty dry season, PCB failure from environmental exposure is one of the most common AC repair causes. Silicon coating meaningfully extends PCB lifespan.
R32 refrigerant: zero ozone depletion, lower GWP than R-410A, higher thermodynamic efficiency. 100% copper condenser coils: better heat transfer than aluminium, easier and cheaper to repair if damaged, more durable in Delhi NCR's dust and humidity. Standard in O General's range.
Five fan speeds versus the standard 3 on most ACs — finer control over airflow rate and noise level. High moisture removal capacity is specifically relevant for Delhi NCR's July–September monsoon when humidity makes rooms feel warmer than the temperature reading suggests.
Auto Restart resumes the last operating settings immediately after power is restored — no manual operation needed during Delhi NCR's frequent load-shedding. Rated for India's 250V/50Hz supply with confirmed voltage compatibility.
📐 Unit Dimensions & Weights
Indoor Unit (IDU)
Size: 83.4 × 23.9 × 27 cm
Net weight: 10 kg
Gross weight: 13 kg
Outdoor Unit (ODU)
Size: 66.3 × 29.0 × 54.1 cm
Net weight: 21 kg
Gross weight: 22 kg
| Brand / Model | O General ASGG12CPAB-B |
| Capacity | 1 Ton |
| BEE Rating | 2-Star |
| Cooling Output | 3520W (~12,000 BTU/h) ✅ |
| Compressor | Hyper Tropical Rotary Inverter |
| High Ambient | 55°C |
| Annual Consumption | 701.66 kWh/year ✅ |
| Refrigerant | R32 (zero ODP · low GWP) |
| Condenser | 100% Copper |
| Airflow | Coanda Technology — 10m reach |
| Fan Speeds | 5 |
| Noise (IDU / ODU) | 45 dB indoor / 48 dB outdoor |
| PCB Protection | Silicon Coated (humidity + dust resistant) |
| Voltage Protection | Up to 700V |
| Voltage / Frequency | 250V / 50Hz ✅ |
| Coverage Area | Up to 100 sq. ft. |
| IDU Dimensions | 83.4 × 23.9 × 27 cm · 10kg net |
| ODU Dimensions | 66.3 × 29.0 × 54.1 cm · 21kg net |
| Warranty | 1-Year Product + 10-Year Compressor + 5-Year ODU PCB (Mahajan exclusive) ✅ |
Why buy from Mahajan Electronics?
- Free standard installation + 3m copper pipe included
- Exclusive 5-Year ODU PCB warranty — only at Mahajan
- 24-hour delivery across Delhi NCR
- GST invoice — save up to 18% on business purchases
- 100% genuine O General products · 45+ years retail trust
- Raja Garden · Jail Road · Dabri Mod · 9710000251
Order today. Free installation. Delivered in 24 hours.
1 Ton · 55°C Hyper Tropical · R32 · Coanda 10m · 700V Protection · 701 kWh/yr · 1+10+5yr Warranty
Source BTU/h figure (1220) is a data entry error — actual ~12,000 BTU/h. Verify on label at delivery. Free installation T&C apply. Image for reference only.
The image shown is for reference only. The actual serial number and manufacturing date may vary.
