Description
5 YEARS COMPREHENSIVE WARRANTY WITH GAS COVER T&C* Till Date-30-09-2026
🎁 Free Standard Installation + 3 Metres Copper Pipe + 5-Year Outdoor PCB Warranty — Exclusive at Mahajan Electronics
Free installation, 3m copper piping, and 5-year outdoor PCB warranty included. 24-hour delivery across Delhi NCR.
➕ Add 4-Year Comprehensive Extended Warranty at ₹6,990 — 2 Service Visits/Year Included
All functional parts covered + 2 scheduled service visits annually. Call 9710000251 / 9310000492 for details.
❄️ O'General 1.8 Ton Inverter. 29 dB. 1170 m³/hr. 55°C CPTA. 25m Pipe. EER 4.43. ASGG22CNWA-B.
The O'General ASGG22CNWA-B is the flagship 1.8-ton model — three library records in one unit: 29 dB minimum noise (the quietest AC in this entire library), 1170 m³/hr airflow (highest in library), and 25-metre maximum piping length (the most flexible installation support). CPTA (Cooling Power for Tropical Applications) compressor rated to 55°C, EER 4.43 W/W, 6400W cooling output for rooms up to 260 sq. ft., Night Glow Remote, Sleep Mode, Auto Restart, Timer, and the full 1-year + 10-year compressor + 5-year outdoor PCB warranty. Free installation and 3m piping exclusively at Mahajan Electronics.
🔇 29 dB minimum — the quietest AC in the entire Mahajan Electronics library
- 29 dB is at the threshold of a whisper and below the ambient noise level of a very quiet room (typically 30–35 dB) — at minimum speed, the ASGG22CNWA-B is effectively inaudible against normal room background noise
- This contrasts with the library's typical range: Voltas Vectra Emerald (28 dB minimum — comparable), LG DUAL Inverter (varies, typically 33–38 dB), Blue Star 3-Star range (48–51 dB), window ACs (56 dB). The ASGG22CNWA-B matches the Vectra Emerald as the quietest in the library despite being a 1.8-ton unit — achieving low noise at higher capacity requires more sophisticated motor and fan engineering
- The 29–50 dB range reflects the inverter's wide speed modulation: 29 dB at minimum load (overnight mild conditions) to 50 dB at maximum output (peak afternoon cooling). For an 8-hour overnight run in a bedroom, the operating point will be in the 29–35 dB range for most of the night
- Night Glow Remote completes the bedroom-optimised specification — backlit buttons for temperature adjustment in the dark without turning on lights or waking other occupants
EER 4.43 W/W — exceptionally high efficiency for a 1.8-ton inverter
EER (Energy Efficiency Ratio) measures cooling output (W) divided by power input (W) — higher is better. At 4.43 W/W, the ASGG22CNWA-B delivers 4.43 watts of cooling for every watt consumed, which is in the upper tier for 3-Star 1.8-ton inverter ACs. The 1068 kWh/year annual consumption figure (not stated in source — confirm from BEE label) at 1.8-ton capacity reflects genuine efficiency rather than a capacity trade-off. For buyers running a 1.8-ton AC 6–8 hours daily across Delhi NCR's 8-month cooling season, the EER differential vs a standard 3-Star model compounds meaningfully over the AC's service life.
1170 m³/hr — the highest airflow in the entire split AC library, on a 1.8-ton unit
1170 m³/hr means the unit cycles the full air volume of a 260 sq. ft. room approximately 6–8 times per hour — ensuring consistent temperature throughout the space including areas away from the indoor unit. The 1.8-ton ASGG22CNWA-B achieves this airflow while maintaining 29 dB minimum noise — a combination that requires precisely designed fan blade geometry and motor balancing. Combined with the 25-metre maximum piping length, this model supports the most demanding installation scenarios in the range: large rooms with complex piping routes where the indoor unit must still deliver high-volume airflow without amplified noise from longer duct paths.
25m Maximum Piping
The longest piping support in the library — accommodates ground-floor indoor units with rooftop outdoor units, large home layouts where the nearest external wall is far from the desired AC position, and multi-storey commercial installations requiring extended pipe runs.
Night Glow Remote
Backlit remote buttons visible in complete darkness — for overnight temperature adjustments without switching on room lighting. A small but meaningful feature for shared bedrooms and consistent overnight comfort management.
Auto Restart + Timer
Auto Restart resumes settings after power cuts without manual reconfiguration. Timer allows scheduling — pre-cool a room before arriving home, or set the AC to switch off at a specific time overnight rather than running unnecessarily after the room reaches comfort.
R32 + Copper
Consistent O'General specification across all three models — R32 eco-refrigerant with zero ODP and copper condenser for superior heat transfer, field repairability, and corrosion resistance across the 1.8-ton unit's full outdoor exposure in Delhi NCR conditions.
🎯 Ideal for
| Brand | O'General (Fujitsu General) |
| Model | ASGG22CNWA-B |
| Type | Inverter Split AC |
| Capacity | 1.8 Ton |
| Energy rating | 3 Star |
| EER | 4.43 W/W |
| Cooling capacity | 6400 W |
| Power consumption | 2.39 kW |
| Compressor | CPTA Inverter (Cooling Power for Tropical Applications) |
| Max ambient temp | 55°C |
| Refrigerant | R32 (Eco-Friendly) |
| Condenser | 100% Copper |
| Airflow volume | 1170 m³/hr (518 CFM) |
| Noise (indoor) | 29–50 dB |
| Noise (outdoor) | 53 dB |
| Operating range | 18°C – 55°C |
| Max piping length | 25 metres |
| Coverage area | Up to 260 sq. ft. |
| Indoor unit (W×H×D) | 980 × 280 × 240 mm / 12.5 kg |
| Outdoor unit | 799 × 632 × 290 mm / 36 kg |
| Country of origin | Made in India |
| Warranty | 1 Yr Comprehensive + 10 Yr Compressor + 5 Yr Outdoor PCB |
🛡️ Complete warranty coverage
29 dB. 1170 m³/hr. 55°C. 25m Pipe. Free Install. Order today.
Order before 2 PM for 24-hour delivery across Delhi NCR. Free installation + 3m piping + 5-yr PCB warranty exclusively at Mahajan Electronics.
Product image shown is for reference only. Actual serial number and manufacturing date may vary. Made in India.
